TS 5000 ECline
ECline guide rail TS 5000 For TS 5000 ECline closer body with opening assistance
- Opening assistance for easy opening and comfortable passing of the door
- Opening assistance can be switched off for doors with wind load or pressure differences
- Easy to replace with the standard guide rail
- With screwed slide block
Application Areas
- Barrier-free access with strongly decreasing opening torque
- Single leaf doors
- Installation on hinge side
- Right and left single-action doors
Installation situations in reference objects and videos
Technical data
ECline guide rail TS 5000 | |
Length | 452.5 mm |
Width | 33 mm |
Height | 30 mm |
Integrated opening assistance | Yes |
Hold-open function | Optional |
Opening assistance can be switched off | Yes |
